Vectorworks Stream Deck Profile
V1All 184 Vectorworks shortcuts on your Stream Deck: Modify (27), Views (17), Layers & Classes (17) + 12 more. One-click install, macOS & Windows.
- 184
- Shortcuts
- 15
- Groups
- macOS · Windows
- Platforms
- 3D
- Category
See it on a deck
The profile as it installs: 14 folders on the home page, 184 shortcuts inside them. Press a folder to open it, a key to see what it fires.
€12.99 Get it on Elgato Open this deck on its own page →
This profile's own key art, drawn by the same code that builds the files you install — and a starting point, not a fixed layout. Once it is imported, every key, folder and page is yours to move, rename, re-icon or delete in the Elgato Stream Deck app. What this page cannot be is the rest of the box: one theme of the ones it ships, two Stream Deck models of six, one platform's key combinations, and no dials.
Version history
Every published revision of this profile, newest first — what changed and why, in the maker's own words.
V1 Oct 14, 2026 Latest version
v1.0 — first release, Vectorworks 2027. 184 shortcuts across 15 folders: Draw Tools, Edit Tools, 3D & Building, 3D Model, Views, Render, Zoom & Pan, Layers & Classes, Modify, Nudge, Snap & Modes, Palettes, File & Edit, Spotlight, Help. Read from Vectorworks' own 2027 shortcut table — every row checked word for word against the PDF, Mac and Windows columns both. One row of that PDF is out of date: Final Shaded Polygon, which Vectorworks 2027 made a legacy mode, is left out. Keys that need a held modifier, a double-tap or a mouse (spring-loaded tools, X-ray, suspend snapping) are left out: a deck key cannot hold or double-tap. Where Vectorworks prints a different default on Mac and Windows (Window, Clip, Connect/Combine, Attribute Mapping and others), each profile sends its own platform's key. Smart Profile binding for Mac and Windows.
All 184 Vectorworks shortcuts
Every action in the profile with its key combination, grouped as it is on the device.
Modify 27
| Action | macOS | Windows |
|---|---|---|
| Move | CMD M | CTRL M |
| Move 3D | CMD ALT M | CTRL ALT M |
| Duplicate | CMD D | CTRL D |
| Duplicate Array | CMD ALT SHIFT D | CTRL ALT SHIFT D |
| Rotate Left 90° | CMD L | CTRL L |
| Rotate Right 90° | CMD SHIFT R | CTRL SHIFT R |
| Flip Horizontal | CMD SHIFT H | CTRL SHIFT H |
| Flip Vertical | CMD SHIFT V | CTRL SHIFT V |
| Align / Distribute | CMD EQUAL | CTRL EQUAL |
| Align / Distribute 3D | CMD SHIFT EQUAL | CTRL SHIFT EQUAL |
| Align to Grid | CMD MINUS | CTRL MINUS |
| Send to Front | CMD F | CTRL F |
| Send Forward | CMD ALT F | CTRL ALT F |
| Send Backward | CMD ALT B | CTRL ALT B |
| Send to Back | CMD B | CTRL B |
| Group | CMD G | CTRL G |
| Ungroup | CMD U | CTRL U |
| Edit Group | CMD BRACKET_LEFT | CTRL BRACKET_LEFT |
| Exit Group | CMD BRACKET_RIGHT | CTRL BRACKET_RIGHT |
| Trim | CMD T | CTRL T |
| Join | CMD J | CTRL J |
| Add Surface | CMD ALT SHIFT A | CTRL ALT SHIFT A |
| Clip Surface | CMD ALT SHIFT C | CTRL ALT SHIFT C |
| Intersect Surface | CMD ALT SHIFT I | CTRL ALT SHIFT I |
| Set Working Plane (Cmd) | CMD BACKSLASH | CTRL BACKSLASH |
| Show Guides | CMD ALT G | CTRL ALT G |
| Hide Guides | CMD ALT SHIFT G | CTRL ALT SHIFT G |
Views 17
| Action | macOS | Windows |
|---|---|---|
| Top / Plan | CMD 5 | CTRL 5 |
| 3D View | CMD 0 | CTRL 0 |
| Front | NUMPAD_2 | NUMPAD_2 |
| Back | NUMPAD_8 | NUMPAD_8 |
| Left | NUMPAD_4 | NUMPAD_4 |
| Right | NUMPAD_6 | NUMPAD_6 |
| Top (3D) | NUMPAD_5 | NUMPAD_5 |
| Left Isometric | NUMPAD_1 | NUMPAD_1 |
| Right Isometric | NUMPAD_3 | NUMPAD_3 |
| Left Rear Isometric | NUMPAD_7 | NUMPAD_7 |
| Right Rear Isometric | NUMPAD_9 | NUMPAD_9 |
| Multiple View Panes | M | M |
| Create Viewports | CMD SHIFT M | CTRL SHIFT M |
| Walkthrough | SHIFT U | SHIFT U |
| Flyover | SHIFT C | SHIFT C |
| Translate View | SHIFT V | SHIFT V |
| Rotate View | SHIFT W | SHIFT W |
Layers & Classes 17
| Action | macOS | Windows |
|---|---|---|
| Layers: Active Only | CMD ALT 3 | CTRL ALT 3 |
| Layers: Gray Others | CMD ALT 4 | CTRL ALT 4 |
| Layers: Gray/Snap Others | CMD ALT 5 | CTRL ALT 5 |
| Layers: Show Others | CMD ALT 6 | CTRL ALT 6 |
| Layers: Show/Snap Others | CMD ALT 7 | CTRL ALT 7 |
| Layers: Show/Snap/Modify Others | CMD ALT 9 | CTRL ALT 8 |
| Classes: Active Only | CMD ALT SHIFT 3 | CTRL ALT SHIFT 3 |
| Classes: Gray Others | CMD ALT SHIFT 4 | CTRL ALT SHIFT 4 |
| Classes: Gray/Snap Others | CMD ALT SHIFT 5 | CTRL ALT SHIFT 5 |
| Classes: Show Others | CMD ALT SHIFT 6 | CTRL ALT SHIFT 6 |
| Classes: Show/Snap Others | CMD ALT SHIFT 7 | CTRL ALT SHIFT 7 |
| Classes: Show/Snap/Modify Others | CMD ALT SHIFT 8 | CTRL ALT SHIFT 8 |
| Active Layer Up | CMD UP | CTRL UP |
| Active Layer Down | CMD DOWN | CTRL DOWN |
| Active Class Left | CMD LEFT | CTRL LEFT |
| Active Class Right | CMD RIGHT | CTRL RIGHT |
| Organization | CMD SHIFT O | CTRL SHIFT O |
Draw Tools 16
| Action | macOS | Windows |
|---|---|---|
| Selection | X | X |
| Text | 1 | 1 |
| Callout | ALT 1 | ALT 1 |
| Line | 2 | 2 |
| Double Line | ALT 2 | ALT 2 |
| Rectangle | 4 | 4 |
| Rounded Rect | ALT 4 | ALT 4 |
| Circle | 6 | 6 |
| Oval | ALT 6 | ALT 6 |
| Arc | 3 | 3 |
| Polyline | 5 | 5 |
| 2D Polygon | 8 | 8 |
| Regular Polygon | ALT SHIFT R | ALT SHIFT R |
| 2D Locus | 0 | 0 |
| Insert Symbol | ALT 0 | ALT 0 |
| Eyedropper | SHIFT E | SHIFT E |
File & Edit 15
| Action | macOS | Windows |
|---|---|---|
| Save | CMD S | CTRL S |
| Undo | CMD Z | CTRL Z |
| Redo | CMD Y | CTRL Y |
| Repeat Last | R | R |
| Cancel | ESCAPE | ESCAPE |
| Select All | CMD A | CTRL A |
| Cut | CMD X | CTRL X |
| Copy | CMD C | CTRL C |
| Paste | CMD V | CTRL V |
| Paste in Place | CMD ALT V | CTRL ALT V |
| New | CMD N | CTRL N |
| Open | CMD O | CTRL O |
| Close | CMD W | CTRL W |
| Save As | CMD SHIFT S | CTRL SHIFT S |
| CMD P | CTRL P |
Edit Tools 14
| Action | macOS | Windows |
|---|---|---|
| Reshape | MINUS | MINUS |
| Rotate | ALT EQUAL | ALT EQUAL |
| Mirror | EQUAL | EQUAL |
| Split | L | L |
| Connect / Combine | ALT L | SEMICOLON |
| Trim Tool | ALT SHIFT L | ALT SHIFT L |
| Fillet | 7 | 7 |
| Chamfer | ALT 7 | ALT 7 |
| Offset | SHIFT MINUS | SHIFT MINUS |
| Clip | ALT C | SHIFT N |
| Move by Points | SHIFT M | SHIFT M |
| Visibility | V | V |
| Texture | SHIFT T | SHIFT T |
| Attribute Mapping | ALT A | SHIFT A |
3D & Building 14
| Action | macOS | Windows |
|---|---|---|
| Wall | 9 | 9 |
| Door | ALT SHIFT D | ALT SHIFT D |
| Window | ALT SHIFT W | SHIFT D |
| Wall Join | ALT J | ALT J |
| Component Join | ALT SHIFT J | ALT SHIFT J |
| Push / Pull | SHIFT R | SHIFT R |
| Set Working Plane | SHIFT 1 | SHIFT 1 |
| NURBS Curve | SHIFT 7 | SHIFT 7 |
| Sphere | SHIFT 3 | SHIFT 3 |
| Fillet Edge | SHIFT F | SHIFT F |
| Chamfer Edge | SHIFT J | SHIFT J |
| Shell Solid | SHIFT G | SHIFT G |
| Project | SHIFT SEMICOLON | SHIFT SEMICOLON |
| Light | SHIFT Z | SHIFT Z |
Zoom & Pan 13
| Action | macOS | Windows |
|---|---|---|
| Zoom In | CMD 1 | CTRL 1 |
| Zoom Out | CMD 2 | CTRL 2 |
| Fit to Objects | CMD 6 | CTRL 6 |
| Fit to Page | CMD 4 | CTRL 4 |
| Normal Scale | CMD 3 | CTRL 3 |
| Zoom Tool | C | C |
| Pan Tool | H | H |
| Pan Up | UP | UP |
| Pan Down | DOWN | DOWN |
| Pan Left | LEFT | LEFT |
| Pan Right | RIGHT | RIGHT |
| Previous View | CMD SHIFT COMMA | CTRL SHIFT COMMA |
| Next View | CMD SHIFT PERIOD | CTRL SHIFT PERIOD |
Snap & Modes 12
| Action | macOS | Windows |
|---|---|---|
| SmartCursor Cues | Y | Y |
| Snap Loupe | Z | Z |
| Set Datum | G | G |
| Snap Lock | T | T |
| Relative Angles | SLASH | SLASH |
| Auto Working Plane | BACKSLASH | BACKSLASH |
| Tool Mode 1 | U | U |
| Tool Mode 2 | I | I |
| Tool Mode 3 | O | O |
| Tool Mode 4 | P | P |
| Tool Mode 5 | BRACKET_LEFT | BRACKET_LEFT |
| Tool Mode 6 | BRACKET_RIGHT | BRACKET_RIGHT |
Palettes 10
| Action | macOS | Windows |
|---|---|---|
| Object Info | CMD I | CTRL I |
| Activate Object Info | CMD ALT C | CTRL BACKTICK |
| Resource Manager | CMD R | CTRL R |
| Attributes | CMD SHIFT A | CTRL SHIFT A |
| Navigation | CMD SHIFT N | CTRL SHIFT N |
| Visualization | CMD ALT SHIFT V | CTRL ALT SHIFT V |
| Working Planes | CMD SHIFT K | CTRL SHIFT K |
| Format Text | CMD SHIFT T | CTRL SHIFT T |
| User Origin | CMD 9 | CTRL 9 |
| Quick Search | F | F |
Nudge 8
| Action | macOS | Windows |
|---|---|---|
| Nudge Up | SHIFT UP | SHIFT UP |
| Nudge Down | SHIFT DOWN | SHIFT DOWN |
| Nudge Left | SHIFT LEFT | SHIFT LEFT |
| Nudge Right | SHIFT RIGHT | SHIFT RIGHT |
| Move Up | CMD SHIFT UP | CTRL SHIFT UP |
| Move Down | CMD SHIFT DOWN | CTRL SHIFT DOWN |
| Move Left | CMD SHIFT LEFT | CTRL SHIFT LEFT |
| Move Right | CMD SHIFT RIGHT | CTRL SHIFT RIGHT |
3D Model 7
| Action | macOS | Windows |
|---|---|---|
| Extrude | CMD E | CTRL E |
| Extrude Along Path | CMD ALT X | CTRL ALT X |
| Sweep | CMD ALT W | CTRL ALT W |
| Add Solids | CMD ALT A | CTRL ALT A |
| Subtract Solids | CMD ALT S | CTRL ALT S |
| Intersect Solids | CMD ALT I | CTRL ALT I |
| Section Solids | CMD ALT T | CTRL ALT T |
Spotlight 7
| Action | macOS | Windows |
|---|---|---|
| Spotlight Numbering | CMD ALT SHIFT N | CTRL ALT SHIFT N |
| Find and Modify | CMD ALT SHIFT M | CTRL ALT SHIFT M |
| Auto Number Positions | CMD ALT SHIFT O | CTRL ALT SHIFT O |
| Focus Lighting Devices | CMD ALT SHIFT F | CTRL ALT SHIFT F |
| Replace Lighting Devices | CMD ALT SHIFT R | CTRL ALT SHIFT R |
| Label Legend Manager | CMD ALT SHIFT L | CTRL ALT SHIFT L |
| Refresh Lighting Devices | CMD SLASH | CTRL SLASH |
Render 6
| Action | macOS | Windows |
|---|---|---|
| Wireframe | CMD SHIFT W | CTRL SHIFT W |
| Shaded | CMD SHIFT G | CTRL SHIFT G |
| Hidden Line | CMD SHIFT E | CTRL SHIFT E |
| Dashed Hidden Line | CMD SHIFT D | CTRL SHIFT D |
| Final Quality Renderworks | CMD SHIFT F | CTRL SHIFT F |
| Sketch Options | CMD ALT SHIFT S | CTRL ALT SHIFT S |
Help 1
| Action | macOS | Windows |
|---|---|---|
| Open Docs | — | — |
Vectorworks keyboard shortcuts on ShortcutPosters → — the same shortcuts as a printable reference, with the source documentation each one was checked against.
Pages per device
184 shortcuts auto-paginate to fit any Stream Deck — one key per page is reserved for navigation.
- Mini
- 37 pages
- Neo
- 27 pages
- MK.2
- 14 pages
- XL
- 6 pages
- +
- 27 pages
- + XL
- 6 pages
Vectorworks profile FAQ
How many shortcuts does the Vectorworks Stream Deck profile include?
184 shortcuts, grouped into 15 sets: Modify (27), Views (17), Layers & Classes (17), Draw Tools (16), File & Edit (15), Edit Tools (14), 3D & Building (14), Zoom & Pan (13), Snap & Modes (12), Palettes (10), Nudge (8), 3D Model (7), Spotlight (7), Render (6), Help (1).
Does the Vectorworks profile fit my Stream Deck?
Yes — it auto-paginates. Mini needs 37 pages, Neo needs 27 pages, MK.2 needs 14 pages, XL needs 6 pages, + needs 27 pages, + XL needs 6 pages.
Can I rearrange the Vectorworks profile after installing it?
Yes — completely. It installs as 14 folders holding 184 shortcuts, and every one of them is yours from that moment: in the official Elgato Stream Deck app you can drag a key to another slot, rename it, change its icon, move it between folders, add your own actions or delete what you don't use. The layout is a starting point, not a lock.
Which operating systems does the Vectorworks profile support?
macOS and Windows. Each shortcut ships with its platform-specific key combination, so one profile covers both.
