CATIA Stream Deck Profile
V1All 47 CATIA shortcuts on your Stream Deck: View (12), Edit (11), Spec Tree (7) + 6 more. One-click install, Windows.
- 47
- Shortcuts
- 9
- Groups
- Windows
- Platforms
- 3D
- Category
See it on a deck
The profile as it installs: 6 folders on the home page, 47 shortcuts inside them. Press a folder to open it, a key to see what it fires.
€7.99 Get it on Elgato Open this deck on its own page →
This profile's own key art, drawn by the same code that builds the files you install — and a starting point, not a fixed layout. Once it is imported, every key, folder and page is yours to move, rename, re-icon or delete in the Elgato Stream Deck app. What this page cannot be is the rest of the box: one theme of the ones it ships, two Stream Deck models of six, one platform's key combinations, and no dials.
Version history
Every published revision of this profile, newest first — what changed and why, in the maker's own words.
V1 Oct 13, 2026 Latest version
v1.0 — first release, CATIA V5 (V5-6R2026). 47 shortcuts across 9 folders: File, Edit, Spec Tree, View, Assembly, Macros, Window & Menus, Help, Workflows. Every key comes from Dassault's own V5 documentation — the Infrastructure keyboard table and the workbench guides — and is identical from V5R19 to R2021. Two are confirmed by independent references only: Update (Ctrl+U) and the VBA editor (Alt+F11). Popular keys that circulate online but that Dassault never assigns — F9 Hide/Show, F10 Swap Visible Space, Space to hide — are left out: they are user customisations. The view keys get their own drawn icons: one cube, and the move each key makes. Windows only. Smart Profile binding to CNEXT.exe.
All 47 CATIA shortcuts
Every action in the profile with its key combination, grouped as it is on the device.
View 12
| Action | Windows |
|---|---|
| Zoom In | CTRL PAGE_UP |
| Zoom Out | CTRL PAGE_DOWN |
| Pan Left | CTRL LEFT |
| Pan Right | CTRL RIGHT |
| Pan Up | CTRL UP |
| Pan Down | CTRL DOWN |
| Rotate Left | SHIFT LEFT |
| Rotate Right | SHIFT RIGHT |
| Rotate Up | SHIFT UP |
| Rotate Down | SHIFT DOWN |
| Roll Left | CTRL SHIFT LEFT |
| Roll Right | CTRL SHIFT RIGHT |
Edit 11
| Action | Windows |
|---|---|
| Update | CTRL U |
| Undo | CTRL Z |
| Redo | CTRL Y |
| Cut | CTRL X |
| Copy | CTRL C |
| Paste | CTRL V |
| Delete | DELETE |
| Search | CTRL F |
| Selection Sets | CTRL G |
| Properties | ALT ENTER |
| Preselection Navigator | CTRL F11 |
Spec Tree 7
| Action | Windows |
|---|---|
| Show / Hide Tree | F3 |
| Tree Overview | SHIFT F2 |
| Activate Tree / Geometry | SHIFT F3 |
| Tree: Go to Top | HOME |
| Tree: Go to Bottom | END |
| Tree: Page Up | PAGE_UP |
| Tree: Page Down | PAGE_DOWN |
Window & Menus 5
| Action | Windows |
|---|---|
| Start Menu (Workbenches) | ALT S |
| Insert Menu | ALT I |
| Tools Menu | ALT T |
| Switch Window | CTRL TAB |
| Escape | ESCAPE |
File 4
| Action | Windows |
|---|---|
| New | CTRL N |
| Open | CTRL O |
| Save | CTRL S |
| CTRL P |
Help 3
| Action | Windows |
|---|---|
| Contextual Help | F1 |
| Help on Icons | SHIFT F1 |
| Open Docs | — |
Assembly 2
| Action | Windows |
|---|---|
| Define Multi-Instantiation | CTRL E |
| Fast Multi-Instantiation | CTRL D |
Macros 2
| Action | Windows |
|---|---|
| Run Macros | ALT F8 |
| Visual Basic Editor | ALT F11 |
Workflows 1
| Action | Windows |
|---|---|
| Update + Save | CTRL U CTRL S |
CATIA keyboard shortcuts on ShortcutPosters → — the same shortcuts as a printable reference, with the source documentation each one was checked against.
Pages per device
47 shortcuts auto-paginate to fit any Stream Deck — one key per page is reserved for navigation.
- Mini
- 10 pages
- Neo
- 7 pages
- MK.2
- 4 pages
- XL
- 2 pages
- +
- 7 pages
- + XL
- 2 pages
CATIA profile FAQ
How many shortcuts does the CATIA Stream Deck profile include?
47 shortcuts, grouped into 9 sets: View (12), Edit (11), Spec Tree (7), Window & Menus (5), File (4), Help (3), Assembly (2), Macros (2), Workflows (1).
Does the CATIA profile fit my Stream Deck?
Yes — it auto-paginates. Mini needs 10 pages, Neo needs 7 pages, MK.2 needs 4 pages, XL needs 2 pages, + needs 7 pages, + XL needs 2 pages.
Can I rearrange the CATIA profile after installing it?
Yes — completely. It installs as 6 folders holding 47 shortcuts, and every one of them is yours from that moment: in the official Elgato Stream Deck app you can drag a key to another slot, rename it, change its icon, move it between folders, add your own actions or delete what you don't use. The layout is a starting point, not a lock.
Which operating systems does the CATIA profile support?
Windows only — every shortcut in it is a Windows combination. The install is one click either way.
